LSZH Fiber Optic Patch Cord MM (OM1) 50/125 1 Meter (SC-Connector/ST-Connector) Duplex (3.0 mm)
Part Number: FLPCO1DX-SC-003-ST-LS
Category: Patch Cord OM1 DX
Payment Methods:
Need Support?
01003962411
01044989983
info@fiblit.com
Pick up from Our Store
Today from 9 am to 6 pm
Indrive, UBER, DiDi delivery
Delivered to specified address
Overview
Features
Key Benefits
Applications
Technical Specs
More Info
Patch Cord SC–ST OM1 DX Overview
The SC–ST OM1 DX Patch Cord is a multimode fiber optic cable designed for duplex (DX) connections using SC and ST connectors. Built with OM1 62.5/125 µm fiber and a durable LSZH jacket, it delivers reliable short-range optical communication in LAN, data center, and enterprise environments. Ideal for connecting patch panels, switches, and multimode equipment requiring mixed connector interfaces.
Patch Cord SC–ST OM1 DX Applications
- Enterprise LAN connectivity
- Data center patch panels and backbone links
- Telecom distribution closets
- Mixed connector infrastructure environments
- Campus and building network wiring
Patch Cord SC–ST OM1 DX Features
- Duplex multimode OM1 62.5/125 µm fiber
- SC/UPC to ST/UPC connectors for mixed interconnect systems
- Low insertion loss for stable signal transmission
- High return loss (≥25 dB) with UPC polish
- LSZH jacket for indoor fire safety and reduced smoke emission
- Factory terminated and tested for quality assurance
- Compatible with standard OM1 networks and equipment
- Available in standard and customized lengths
Patch Cord SC–ST OM1 DX Specifications
| Specification | Details |
|---|---|
| Product Name | Patch Cord SC–ST OM1 DX |
| Part Number | FLPCO1DX-SC-003-ST-LS |
| Connector Type | SC/UPC to ST/UPC |
| Fiber Type | Multimode OM1 (62.5/125 µm) |
| Cable Structure | Duplex (DX) |
| Wavelength | 850 nm / 1300 nm |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 25 dB |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Cable Diameter | 2.0 mm / 3.0 mm |
| Cable Color | Orange (standard MM OM1) |
| Operating Temperature | -20 °C to +70 °C |
| Storage Temperature | -40 °C to +85 °C |
| Compliance | IEC / TIA-568 / RoHS |
| Available Lengths | 1 m, 2 m, 3 m, 5 m, 10 m (custom available) |
Patch Cord SC–ST OM1 DX Benefits
- Reliable duplex optical connectivity for short-range multimode networks
- Mixed connector types support diverse network hardware
- LSZH jacket increases safety in indoor environments
- Low insertion and return loss improve signal quality
- Ideal for LAN, campus, and data center interlinks
- Easy plug-and-play installation
Patch Cord SC–ST OM1 DX FAQs
What fiber type does OM1 support?
OM1 supports multimode 62.5/125 µm fiber used for short-distance multi-gigabit networks.
Can this patch cord be used with legacy equipment?
Yes — SC and ST are common connector types in legacy and current multimode networks.
Are custom lengths available?
Yes — custom lengths are available upon request.
What environments is this cable suited for?
It suits indoor enterprise, data center, and campus network environments.
What is the jacket type?
The LSZH jacket increases safety by reducing smoke and toxic gases if exposed to fire.
